1U 19inch Fiber Optical Distribution Frame ODF Unit Sliding Rack
Mounted
12 Fibers Fiber Optical Distribution Frame ODF Unit Sliding Rack
Mounted 1U Patch Panel
Product Introduction Of Optical Distribution Frame Unit
Begate provides 1U to 8U height ODF unit with capacity from 12 to
144 fibers. ODF unit is a necessary part of the indoor optical
distribution frame. It includes many 12 cores fusion splicing and
distribution module(tray), the tray plays the main role of the
whole product and its function is splicing, fiber storage and
protection. A completed ODF unit is with fiber optic adapter,
pigtail and accessories like splicing protection sleeve, nylon tie,
spiral tube, screw and ,so on. We supply both unloaded empty ODF
without adapter and pigtail or the full fullyed type with adapters
and pigtails.
Main Features Of Fiber ODF Unit
1, Compact design, cancel all unnecessary parts so the cost is much
favormore able and operation is more convenient.
2, Standard 19” width and suitable for standard distribution frame
and cabinet
3, Capacity: 12 to 144 fibers, 12 cores each module
4, The fusion splicing and distribution module is with rolling,
patching, splicand ing function, it is with sliding and can be
pulled out separately.
5, Material of the metal box: steel sheet and aluminum alloy
6, Suitable for simplex SC, FC, ST and LC duplex adapter
7, As for SC, LC and FC, both 0.9mm and 2.0mm pigtail are
available, as for ST pigtail, only 0.9mm is available
Specification Of 12 Cores 1U 19” ODF Patch Panel
| Product Name | ODF Unit |
| Installation Type | Rack Mounted |
| Open way | Sliding Drawer |
| Application | Indoor Optical Distribution Frame or Cabinet |
| Body Material | Cold Rolled Metal Sheet |
| Fiber Capacity | 12 - 144 cores |
| Fiber Tray | 12 fibers each tray |
| Adapter Panel Type | Metal, plastic, replaceable |
| Available Adapter Type | SC Simplex, LC Duplex, ST with square module, FC Simplex Square |
| Painting Color | Grey |
| Surface Treatment | Power spray |
| Assembly | Empty, half loaded or full loaded |
| Dimension | 430x240.4x43.4mm (1U 19” ) |
| Accessories | Fiber Adapter, pigtail, fiber splice tray, door locker, cable
fastener, strengthen member fastener, heat shrinkable sleeve, cable
tie etc. Or customized |
| Customized Paint/Print | Available |
| OEM/ODM | Available, logo, packing, new design, revise, color, else |
