Products Description
High density MPO/MTP fiber patch cord is a fiber optic cable capped
at either end with connectors that allow it to be rapidly and
conveniently connected to CATV, an optical switch, or other
telecommunication equipment. Having a thick layer of protection, it
is used to connect the optical transmitter, receiver, and the
terminal box. This is known as "interconnect-style cabling".
Feature
1).Low Insertion loss
2).High return loss
3).Good Repeatability
4).Good Interchange
5).Excellent Environmental Adaptability
Application
1).Communication rooms
2).FTTH (Fiber to The Home)
3).LAN (Local Area Network)
4).FOS (fiber optic sensor)
5).Fiber Optic Communication System
6).Optical fiber connected and transmitted equipment
7).Defense combat readiness
| Model | Single Mode (G652D,G657A1,G657A2,G657B3) | Multi Mode (OM1,OM2,OM3,OM4) |
| Polish | UPC | APC | UPC |
| Insertion Loss | ≤0.30dB | ≤0.20dB | ≤0.20dB |
| Return Loss | ≥50dB | ≥60dB | ≥30dB |
| Test Wavelength | 1310/1550nm | 850/1310nm |
| Durability(500 Matings) | ≤0.2dB |
| Operating Temperature | -45℃~+70℃ |
| Cable Diameter | 0.9mm, 2.0mm, 3.0mm |
| Cable Length | 1m,2m,3m; Customized |
| Cable Jacket | PVC,LSZH,OFNR,OFNP |
Begate fiber patchcord assembly line
Begate provides a full set of fiber optic patch cords customized
services, such as fiber connector, length, color, fiber grade,
specifications, materials, packaging, etc. All patch cords are
functionally tested before shipping, ensure that the end face is
spotless, insertion loss and return loss are in line with
international telecommunication standards.
Packaging and shipping
Every cooperation is a kind of trust, Begates cares about the
issues that our customers care about.
While ensuring product quality, we provide customers with safe
packaging, so that the goods can be delivered to customers in good
condition.
Question: How long is shipping take typically?
Reply: The delivery time depends on the goods quantities. If light
weight, by express (DHL, FEDEX, TNT, UPS, Special line) will take
about 10-15days, if large quantities with big volume, and goods are
not in urgently needed, by ocean transportation will be more cost
effective, it will take around 30-60days.
Customers` feedback
FAQ
Q1: Are you a manufacturer?
A: Yes, we are a manufacturer who has 3 factories and welcome to
visit!
Q2: What is your MOQ?
A: We are the factory. No MOQ, One piece is available.
Q3:Can you provide the OEM service?
A: Sure, we have the complete production line, we could do the
production as your request.
Q4. Can I have a sample order for this product?
A: Yes, for patchcord, FREE SAMPLE is avaible to test and check quality. Mixed samples are
acceptable.
Q5: How long is your delivery time?
A: Generally it is 2-5days if the goods are in stock. or it is 7-15
days if the goods are out of stock. The lead time mainly depends on
quantity.
Q6: Can I negotiate the prices?
A:Yes, special discounts are available. The more quantities, the
cheaper prices.
Q7: How much will the shipping charges be?
A:It depends on the size of your shipment and the method of
shipping. We will offer the charge to you as per you requested.
