Optical Fiber Patch Cord 3M FC/UPC-FC/UPC Single Mode Factory Good
Price
Product Description
Features:
Low insertion loss and back reflection loss
Good Durability
Good exchangeability
High temperature stability
Specifications:
Insertion Loss: Typical≦ 0.2dB, Maximum≦0.3dB
Return Loss :≧50dB (PC/UPC); ≧65dB (APC)
Repeatability: ≦0.1
Durability ≦0.2dB typical change, 1000 matings
Interchangeability: ≦0.2dB
Tensile Strength : >10kg
Operating Temperature: -40 ~ 85℃
Applications:
CATV / Metro, Active device termination,Telecommunication networks,
Local Area Networks (LANs)Data processing networks, Test equipment,
Premise installations, Wide Area Networks (WANs)
| UNIT | FC, SC, LC, ST, MU | MT-RJ, MPO |
| PARAMETER | SM | MM | SM | MM |
| Insertion Loss | dB | PC | UPC | APC | PC | PC | UPC | PC |
| Return Loss | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 |
| Operating Wavelength | nm | ≥45 | ≥50 | ≥60 | ≥30 | ≥45 | ≥50 | ≥35 |
| Exchangeablity | dB | 1310, 1510 |
| Vibration | dB | ≤0.2 |
| Operation Temperature | ℃ | ≤0.2 |
| Storage Temperature | ℃ | -45℃ to 75℃ |
| Cable Diameter | mm | -45℃ to 85 ℃ |
Applicantion
Assembly line of Optical Fiber Patch Cord
Feedback from Customers
Company information
Shenzhen begate Co., Ltd is located in longhua, Shenzhen. The
factory covers an area of 20,000 square meters, and has a complete
set of automated production and testing equipments. Begate is
specialized in manufacturing of network cables, optical fiber quick
connector, fiber optical cables, fiber optic adaptor, fiber optic
attenuator, fiber optic splitter, professional plc splitter
cassette, fiber optic patch cord, fiber optic splice closure, FTTH
series and other products of network cabling system. Our products
also covers the fiber media converter, Fiber optic cross connect
cabinet and Fiber optic splice closure, etc.
In order to meet more high end market’s needs, we imported REELEX
machine from US and got the National High-Tech Enterprise
Certification in the same year.
We have passed ISO9001-2008 and ISO14001 certification with
excellent management systems.
Our products with owire brand are widely used in projects from 5G
network, medical, aviation, government and banks, health and
education, optical fiber quick connector, construction and real
estate, energy and transportation. In addition to meet the demand
of Chinese market, our products have been exported to USA, UK,
Italy, Denmark, Mexico, Russia, Korea, Singapore, South Africa,
Brazil, Venezuela, Egypt, UAE, etc.
Begate is specialized in manufacturing of network cables, fiber
optical cables, professional fiber optic patchcord, fiber optic
adaptor, fiber optic attenuator, fiber optic splitter, professional
PLC splitter cassette, fiber optic patch cord, fiber optic splice
closure, FTTH series and other products of network cabling system.
These products are approved by UL, CPR, FCC, ISO, CE, ROHS, CCC,
TLC certifications.
As experienced supplier, We are familiar with the needs of our customers. Looking forward
to working with you.
