Good Price High Quality 8 12 24 Fibers Fiber Optic MTP MPO Patch
Cable
Product Description
MTP trunk cable, a cost-effective alternative to time-consuming
field termination, is designed for high-density fiber patching in
data centers which need space saving and reduce cable management
troubles.
0.35dB IL, MTP (MPO) to MTP(MPO) connector and 3.0mm Plenum (OFNP) bunch cable is designed for
40G/100G direct connection and high-density data center
applications.
Applications
1.Data communication network
2.Optical system access network
3.Storage area network fiber channel
4.High density architectures
Features and benefits
1.100% pre-terminated and tested in factory to ensure transfer
performance
2.Rapid configuration and networking, reduce installation time
3.Supports 40G and 100G network applications
4.Jacket material: LSZH, OFNR, OFNP available
5.Supports up to 12F, 24F, 48F, 72F, 96F, 144F, customized products
are available
Technical Parameter
| Perfomance Level | Standard | Elite |
| Connector | Mode | Endface | IL(mas)(dB) | RL(min)(dB) | IL(max)(dB) | RL(min)(dB) |
| MPO/MTP | SM | 12F/APC | ≤0.70 | ≥60 | ≤0.35 | ≥60 |
| MM | 24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 |
Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1330nm;
2.Standard conformance:GR-326,GR-1436. |
|
|
|
| Mechanical Properties |
| Item | Criteria | Conformance |
| △IL Ater 50 Matings | MPO/MTP | ≤0.3dB | GR-1435 |
| △IL Ater 500 Matings | LC/SC/FC/ST | ≤0.2dB | IEC 61300-2-2 |
| Min Bend Radius(Dynamic) | 20xOD(Cable Diameter) |
| Min Bend Radius(Static) | 15xOD(Cable Diameter) |
|
| Environment Conditions |
| Item | Criteria | Conformance |
| Operation Temperature | "-40~60℃ | IEC 61753-1 |
| Storage Temperature | "-40~85℃ |
Production Process of MPO MTP Cable:
Other Type of MPO MTP Cable:
Company information
Shenzhen begate Co., Ltd is located in longhua, Shenzhen. The
factory covers an area of 20,000 square meters, and has a complete
set of automated production and testing equipments. Begate is
specialized in manufacturing of network cables, optical fiber quick
connector, fiber optical cables, fiber optic adaptor, fiber optic
attenuator, fiber optic splitter, professional plc splitter
cassette, fiber optic patch cord, fiber optic splice closure, FTTH
series and other products of network cabling system. Our products
also covers the fiber media converter, Fiber optic cross connect
cabinet and Fiber optic splice closure, etc.
In order to meet more high end market’s needs, we imported REELEX
machine from US and got the National High-Tech Enterprise
Certification in the same year.
We have passed ISO9001-2008 and ISO14001 certification with
excellent management systems.
Our products with owire brand are widely used in projects from 5G
network, medical, aviation, government and banks, health and
education, optical fiber quick connector, construction and real
estate, energy and transportation. In addition to meet the demand
of Chinese market, our products have been exported to USA, UK,
Italy, Denmark, Mexico, Russia, Korea, Singapore, South Africa,
Brazil, Venezuela, Egypt, UAE, etc.
Begate is specialized in manufacturing of network cables, fiber
optical cables, professional fiber optic patchcord, fiber optic
adaptor, fiber optic attenuator, fiber optic splitter, professional
PLC splitter cassette, fiber optic patch cord, fiber optic splice
closure, FTTH series and other products of network cabling system.
These products are approved by UL, CPR, FCC, ISO, CE, ROHS, CCC,
TLC certifications.
As experienced supplier, We are familiar with the needs of our customers. Looking forward
to working with you.
